Product Features:
■ Bed rail grinding, high precision.
■ CE conformity, electromagnetic brake can be amounted.
■ Screw overload torque protection.
■ Light bars overload protection.
■ Fast feed (special order).
■ Precision ball bearings supporting.
■ Customizable CD6166B/CD6266B & Mechanical clutch.
Standard Accessories:
■ Reduction sleeves ■ Centers ■ Three jaw chuck ■ Changing gears ■ Tool box and tools 1 set
Special Accessories:
■ Four jaw chuck ■ Face plate ■ Steady rest ■ Follow rest ■ Live center ■ Bed base ■ Work light ■ Foot brake ■ Coolant
Specification | CD6240B/C | CD6250B/C | CD6260B/C |
Max.swing over bed | Φ400mm | Φ500mm | Φ600mm |
Max.swing over cross slide | Φ225mm | Φ325mm | Φ360mm |
Max.swing over gap | Φ550mm | Φ630mm | Φ730mm |
Effective length of gap | 260mm | ||
Center Distance | 1000mm/1500mm/2000mm/3000mm | ||
Bed Width | 330mm | ||
Spindle hole | B:Φ65mm,C: Φ80mm | ||
Spindle nose | B:ISO-D6,C:ISO-D8 | ||
Spindle speed(Number) | B:20-1800rpm(15steps) C:/24-1600rpm(15steps) | ||
Longitudinal feeds range | 66kinds 0.072-4.038mm/rev(0.0027-0.15inch/rev) | ||
Cross feeds range | 66kinds 0.036-2.019mm/rev(0.0013-0.075inch/rev) | ||
Metric threads range | 66kinds 0.5-28 | ||
Inch threads range | 66kinds 1-56inch | ||
Module threads range | 33kinds 0.5-3.5mπ | ||
Diametric threads range | 33kinds 8-56D.P | ||
Max.travel of top slide | 130mm | ||
Max.travel of cross slide | 300mm | ||
Max.size of tool shank | 20×20mm/25×25mm | ||
Dia.of tailstock sleeve | Φ65mm | ||
Taper of tailstock sleeve | MT5 | ||
Max.travel of tailstock | 120mm | ||
Main drive motor | 5.5kw or 7.5kw | ||
Rapid traverse motor | 250w | ||
Coolant pump motor | 125w | ||
Packing size | 1000mm:2420mm×1150mm×1800mm 1500mm:2920mm×1150mm×1800mm 2000mm:3460mm×1150mm×1800mm 3000mm:4720mm×1150mm×1800mm | ||
N.W/G.W | 1000mm:1560/2210kgs 1600/2250kgs 1640/2290kgs 1500mm:1770/2410kgs 1830/2470kgs 1870/2530kgs 2000mm:2010/2780kgs 2070/2820kgs 2130/2860kgs 3000mm:2400/3200kgs 2460/3260kgs 2580/3400kgs | ||
